Solar Plus Csslr Plus overstrømningsventil 3⁄4 vinkel. Indstillingsområde 0,2 - 0,6 bar. Max tryk 10 bar. Max temperatur 110°C

Solar Plus overstrømningsventil ¾'''' vinkel.USV overstrømningsventil er en selvvirkende reguleringsventil til varmeanlæg.USV ventilen anvendes til at opretholde en minimum gennemstrømning i anlægget.Indstillingsområde 0,2 - 0,6 bar.Max tryk 10 bar.Max temperatur 110 grader.Fremstillet i messing CW617Relief valve for systems with automatic or manual shut-off elements on theradiators (thermostatic valves, two-way zone valves). Female inlet connections,Male union outlet. Body and cap of brass CW617N.Adjustment : Position ''0'' = Fully open - Position ''7'' = Close to closing ?p =0.5 barPlastic knob. Max operating pressure : 6 bar.Overpressure : 10 - 15%. Max operating temperature : 110°CBy-pass valve series USVR can be set in this way:• Thighten blocking screw (1) (see overall dimensions).• Set the USVR valve at the differential opening pressure ?P by turning regulation knob (2) (see overall dimensions).The differential opening pressure DP shall exceed the user circuit load loss at rated discharge by approximately20% in order that avoid valve opening be prevented. When the user circuits is completely closed, the USVRvalve shall be fully open.• Turn regulation knob anticlockwise untilscale (3) (see overall dimensions) indicates zero. Then proceed, turningclockwise, to calibration setting at the number required. Each number from 0-7 revers to an USVR16 - USVR20USVR25 - USVR32.• Once the correct setting is established, it can be fixed with the locking screw of the handwheel "overstrømningsventil 3/4" vinkel"
