Huawei sun2000-115ktl m2 inverter

Huawei sun2000-115ktl m2 inverter

Huawei SUN2000-115KTL M2 3-faset Smart String Inverter 400V, effekt på 115kW. 10 MPP tracker. Dongle er tilkøb, 5 års garanti.Technical SpecificationsInput :Max. Input Voltage 1,100 V Note *1Max. Current per MPPT 30 AMax. Current per Input 20 AMax. Short Circuit Current per MPPT 40 AStart Voltage 200 VMPPT Operating Voltage Range 200 V ~ 1,000 V Note *2Nominal Input Voltage 600 V @400 Vac, 720 V @480 VacNumber of MPP trackers 10Max. input number per MPP tracker 2Output :Nominal AC Active Power 115,000 WMax. AC Apparent Power 125,000 VAMax. AC Active Power (cosf=1) 125,000 WNominal Output Voltage 400 V / 480 V, 3W+(N)+PERated AC Grid Frequency 50 Hz / 60 HzNominal Output Current 166.0 A @400 V, 138.4 A @480 VMax. Output Current 182.3 A @400 V, 151.9 A @480 VCommunication : Display LED indicators; WLAN adaptor + FusionSolar APPRS485 : YesUSB : YesSmart Dongle-4G Smart Dongle : 4G eller WLAN (Tilkøb)Monitoring BUS (MBUS) : Yes (isolation transformer required)General : Dimensions (W x H x D) 1,035 x 700 x 365 mmWeight (with mounting plate) = 93 kgOperating Temperature Range -25°C ~ 60°CCooling Method Smart Air CoolingMax. Operating Altitude 4,000 m (13,123 ft.)Relative Humidity 0 ~ 100%DC Connector Amphenol Helios H4AC Connector Waterproof Connector + OT/DT TerminalProtection Degree IP66Topology TransformerlessStandard ComplianceEN 62109-1/-2, IEC 62109-1/-2, EN 50530, IEC 62116, IEC 61727, IEC 60068, IEC 61683Grid Connection StandardsVDE-AR-N4105, EN 50549-1, EN 50549-2, RD 661, RD 1699, C10/11*1 The maximum input voltage is the upper limit of the DC voltage. Any higher input DC voltage would probably damage inverter.*2 Any DC input voltage beyond the operating voltage range may result in inverter improper operating. Huawei sun2000-115ktl m2 inverter
