Rækkeklemme Weidmüller A2C 16 A-serie Universal - beige

Weidmüller A2C 16 Reihenklemmen A-Reihe Universal 2494000000 Weidmüller A2C 16 terminal block Weidmüller A2C 16, 12 mm, 51.5 mm, 80.5 mm, 1000 V Weidmüller A2C 16. Width: 12 mm, Depth: 51.5 mm, Height: 80.5 mm. Rated voltage: 1000 V To feed through power, signal, and data is the classical requirement in electrical engineering and panel building. The insulating material, the connection system and the design of the terminal blocks are the differentiating features. A feed-through terminal block is suitable for joining and/or connecting one or more conductors. They could have one or more connection levels that are on the same potential or insulated against one another. Technical details Number of poles: 1 Product colour: Beige Contact resistance: 0.42 mΩ Material: Wemid Current: 76 A Lateral section: 16 mm² Cable section (AWG): 18 - 4 Feature: Sustainability compliance Type: Single level terminal block Compliance certificates: CE, RoHS Operating temperature (T-T): -25 - 55 °C Weight & dimensions Width: 12 mm Depth: 51.5 mm Height: 80.5 mm Power Rated voltage: 1000 V...
