ABB Automatsikring c 4a 2-polet c-karakteristik brydeevne 6ka 230/400v ac 35mm bred s202-c4

ABB Sicherungsautomat 4A Pro M S202-C4 Comp.2POL.6KA für Leitungssch. ABB S202-C4 circuit breaker ABB S202-C4, Miniature circuit breaker, IP20 ABB S202-C4. Input current: 4 A, Input frequency: 50 - 60 Hz, Rated voltage: 400 V. Circuit breaker type: Miniature circuit breaker, International Protection (IP) code: IP20, Protection class: III. Width: 35 mm, Depth: 69 mm, Height: 88 mm System pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077 allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200 to save 50% space. Power Input current: 4 A Input frequency: 50 - 60 Hz Rated voltage: 400 V Total power loss: 3.6 W Features Circuit breaker type: Miniature circuit breaker Number of poles: 2 International Protection (IP) code: IP20 Protection class: III Product colour: Grey Operational conditions Operating temperature (T-T): -25 - 55 °C Storage temperature (T-T): -40 - 70 °C Weight & dimensions Width: 35 mm Depth: 69 mm Height: 88 mm Weight: 250 g Technical details Compliance certificates: RoHS...
