LevelOne SFP-3001 SFP (mini-GBIC) transceiver modul Gigabit Ethernet

LevelOne SFP / Multi-Mode / LevelOne SFP-3001 network transceiver module LevelOne 1.25Gbps Multi-mode SFP Transceiver, 500m, 850nm, Fiber optic, 1250 Mbit/s, SFP, LC, 50/125,62.5/125 µm, 550 m LevelOne 1.25Gbps Multi-mode SFP Transceiver, 500m, 850nm. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1250 Mbit/s, Interface type: SFP. Input voltage: 3.3 V, Maximum voltage: 6 V, Maximum current: 0.3 A. Compliance certificates: RoHS, Safety: EN 60825-1, Certification: CE, FCC. Width: 57 mm, Depth: 12 mm, Height: 13.7 mm. Quantity per pack: 1 pc(s) LevelOne SFP-3001 is a high performance and costeffective multi-mode SFP transceiver. Intended for use with Gigabit Ethernet, it provides up to 1.25 Gbps bidirectional data transfer rate on a single duplex fiber core. For use with 50 and 62.5 micron fiber cables, it can reach a distance of up to 550 meters. - 850nm VCSEL - Data Rate: 1.25Gbps - Single +3.3V Power Supply - RoHS Compliant and Lead-free - AC/AC Differential Electrical Interface - Compliant with Multi-Source Agreement(MSA) - Duplex LC Connector - Compliance with specifications for IEEE 802.3z Gigabit Ethernet at 1.25Gbps - Compliance with ANSI specifications for Fiber Channel applications at 1.06bps - No configuration or installation software required - Eye Safety Designed to meet LASER Class 1 comply with EN60825-1 Performance SFP transceiver type: Fiber optic Maximum data transfer rate: 1250 Mbit/s Interface type: SFP Feature: Multi-mode fiber (MMF) supported Fiber optic connector: LC Fiber cable diameters supported (core/cladding): 50/125,62.5/125 µm Maximum transfer distance: 550 m Wavelength: 850 nm Tx power (min): -9.5 dBmW Tx power (max): -3 dBmW Networking standards: IEEE 802.3z Duplex system: Full Fiber ports quantity: 1 Features Feature: Plug and Play Feature: Hot-swap Power Input voltage: 3.3 V Maximum voltage: ...
