LevelOne GVT-0300 SFP (mini-GBIC) transceiver modul Gigabit Ethernet

LevelOne Mini GVT-0300 / SX LevelOne GVT-0300 network transceiver module LevelOne 1.25Gbps Multi-mode SFP Transceiver, 550m, 850nm, Fiber optic, 1250 Mbit/s, SFP, LC, 50/125,62.5/125 µm, SX LevelOne 1.25Gbps Multi-mode SFP Transceiver, 550m, 850nm. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1250 Mbit/s, Interface type: SFP. Compatible products: GSW-2453 GVT-4000. Input voltage: 3.5 V, Maximum voltage: 6 V, Maximum current: 0.3 A. Certification: Class 1 Laser: EN60825-1 FDA 21: 1040.10, 1040.11. Width: 13.4 mm, Depth: 56.6 mm, Height: 8.4 mm Product Overview The LevelOne GVT-0300 SFP (Small form-factor pluggable) fiber optic transceiver provides fullduplex connectivity over multi-mode fiber at distances up to 550 meters. GVT-0300 is designed for use in Gigabit Ethernet networks to provide an IEEE-802.3z-compliant link for 1.25 Gb/s speeds to serve short-range applications. GVT-0300 operates at a nominal wavelength of 850nm and complies with a Multi-Source Agreement (MSA) for compatibility between manufacturers. It comes with a click-and-latch LC connector for a solid connection into the SFP port. Multi-Purpose Usage GVT-0300 can be used for distributed multiprocessing, switch-to-switch, converterto-switch, or converter-to converter interfaces, high-speed I/O file transfer, bus extension applications, and as a channel extender in data storage applications. LevelOne GVT-0300 can be used in any LevelOne switch or converter that can accommodate SFP (Mini-GBIC) transceivers. - Small Form Factor Pluggable MSA compliant - For Multi-mode Applications - Up to 850nm & 1.25Gbps - Compliant for IEEE802.3z Gigabit Ethernet - Easy to install and Hot-pluggable - Connect switches up to 550m away with each other - Single 3.3V power supply - Duplex LC Connector - TTL signal detect indicator - EEPROM with serial ID functionality Performance SFP transceiver type: Fiber opt...
