Hjælpekontaktblok Siemens 3RH19211CA01 - 1 NC

Siemens 3RH19211CA01 Hilfsschalterblock 1 DIN EN50005 Schraubanschluss 1p Siemens 3RH1921-1CA01 auxiliary contact Siemens AUXILIARY SWITCH BLOCK, 1 NC,, 18 g, 114 mm, 47 mm, 55 mm Siemens AUXILIARY SWITCH BLOCK, 1 NC,. Package weight: 18 g, Package depth: 114 mm, Package width: 47 mm front-side auxiliary switch, 1 NC contact, screw terminal, for contactors 3RT1 auxiliary switch SIRIUS 3RH19 for the expansion of auxiliary contacts in the control circuit. This 3RH19 auxiliary switch can be fitted to 3RT1 contactors and 3RH1 contactor relays of sizes S0-S12 without the need for tools. The 3RH19/3RH29 auxiliary switches are available as versions for front or lateral mounting, with up to four instantaneous contacts or up to two leading NO and NC contacts. The auxiliary switches can be designed as positively driven contacts in 3RH contactor relays or also as mirror contacts in the case of 3RT power contactors. All of them are available with screw terminal and spring-type terminal. Simple, efficient and always up to date - SIRIUS modular system. Technical details Compliance certificates: CE, RoHS Rated operation current (Ie at AC-15, 230V): 6 A Electrical connection type: Screw connection Number of NC contacts: 1 Mounting method: Other Minimum order quantity: 1 pc(s) Maximum order quantity: 1 pc(s) Lamp holder: None Weight & dimensions Package weight: 18 g Package depth: 114 mm Package width: 47 mm Package height: 55 mm...
